Introduction
Mastering ECG arrhythmia interpretation UKMLA candidates need is non-negotiable for success in the exam and safe clinical practice. Arrhythmias, or abnormal heart rhythms, range from benign variations to life-threatening emergencies. The electrocardiogram (ECG) is your primary tool for diagnosing these disturbances, guiding immediate management, and potentially saving a life. Being able to rapidly and accurately interpret a rhythm strip is a fundamental skill.
This guide builds upon the foundations laid in The Ultimate Guide to High-Yield ECG Topics for the UKMLA, focusing specifically on arrhythmias. We’ll provide a robust 7-step framework dedicated to rhythm analysis, delve into the common tachycardias and bradycardias you must know, highlight the critical cardiac arrest rhythms, and help you integrate these findings into clinical scenarios.
Key Takeaways
Â
Systematic Approach is Key: Always use a structured method (Rate, Rhythm, P waves, PR interval, QRS width, QRS morphology, Overall Pattern) to analyse rhythms accurately.
Narrow vs. Broad is Crucial: The QRS width is the primary differentiator between supraventricular (narrow) and ventricular (broad) tachycardias, guiding immediate management.
Regular vs. Irregular Matters: Distinguishing between regular and irregular rhythms quickly narrows down the differential diagnosis (e.g., irregularly irregular = AF).
Identify Life-Threatening Rhythms First: Prioritise recognising shockable rhythms (VT, VF) and high-degree AV blocks in bradycardias.
Contextualise Findings: Always interpret the ECG rhythm strip in the context of the full 12-lead ECG (for ischaemia, axis etc.) and the patient’s clinical condition (stable vs. unstable).
Why Arrhythmia Recognition is Critical for UKMLA Success
The ability to identify and respond appropriately to arrhythmias is a core competency tested throughout the UKMLA.
The AKT Context: Linking Rhythms to Clinical Scenarios
In the Applied Knowledge Test (AKT), you will encounter questions that require you to identify an arrhythmia from a rhythm strip presented within a clinical vignette. You might need to diagnose atrial fibrillation in a patient presenting with palpitations, recognise complete heart block in someone with syncope, or identify ventricular tachycardia in a peri-arrest scenario. Success requires not just pattern recognition but understanding the clinical implications, a key aspect of how to Master Interpreting Clinical Data: UKMLA AKT 5-Step Guide.
The CPSA Context: Managing Acutely Unwell Patients
The Clinical and Professional Skills Assessment (CPSA) tests your ability to act. You might face stations involving:
Acute Scenarios: Interpreting a rhythm strip on a monitor for a simulated acutely unwell patient (e.g., hypotensive, chest pain) and initiating appropriate management (e.g., calling for help, starting ALS algorithm).
Communication: Explaining a diagnosis like atrial fibrillation or the need for a pacemaker to a patient or their family.
Procedural Skills: Demonstrating safe cardioversion or pacing (on a manikin), which requires correct rhythm identification first.
The 7-Step Framework for ECG Arrhythmia Interpretation UKMLA
Resist the urge to jump to conclusions. A systematic analysis prevents errors. Apply these steps rigorously to every rhythm strip.
Step 1: Rate (Fast, Slow, Normal?)
Determine the Ventricular Rate: How many QRS complexes per minute? (Normal 60-100 bpm).
✓ Regular Rhythms: Use the 300 method (300 / number of large squares between R waves).
✓ Irregular Rhythms: Count QRS complexes on the 10-second rhythm strip and multiply by 6.
Determine the Atrial Rate (if possible): How many P waves per minute? Are they the same as the ventricular rate?
Step 2: Rhythm (Regular or Irregular?)
Assess Ventricular Rhythm: Is the R-R interval constant? Use paper or calipers.
✓ Regular: Consistent R-R interval.
✓ Regularly Irregular: A pattern to the irregularity (e.g., Mobitz I).
✓ Irregularly Irregular: Completely chaotic (hallmark of Atrial Fibrillation).
Assess Atrial Rhythm (if P waves visible): Is the P-P interval constant?
Step 3: P Waves (Present? Related to QRS?)
Are P waves visible? Look closely in leads II and V1.
What is their morphology? Are they uniform? Upright in lead II? (Peaked = P pulmonale, Bifid = P mitrale).
Is there one P wave for every QRS?
Is the P wave related to the QRS? Does it consistently precede the QRS complex?
Step 4: PR Interval (Constant? Short? Long?)
Measure: From the start of the P wave to the start of the QRS complex.
Normal: 0.12 – 0.20 seconds (3-5 small squares).
Ask:
Is it constant?
Is it short (<0.12s)? Suggests accessory pathway (e.g., WPW).
Is it long (>0.20s)? Suggests AV block (First-degree if constant).
Does it vary? (e.g., progressively lengthening in Mobitz I).
Step 5: QRS Width (Narrow or Broad?)
Measure: From the beginning to the end of the QRS complex.
Normal (Narrow): <0.12 seconds (3 small squares). Implies supraventricular origin.
Abnormal (Broad): ≥0.12 seconds (3 small squares). Implies ventricular origin OR supraventricular origin with aberrant conduction (e.g., bundle branch block).
This is CRITICAL for classifying tachycardias.
Step 6: QRS Morphology (Specific Patterns?)
Are there specific shapes?
✓ Delta Wave: Slurred upstroke suggests pre-excitation (WPW).
✓ Bundle Branch Block: RBBB (MaRRoW in V1/V6) or LBBB (WiLLiaM in V1/V6).
✓ Ventricular Ectopics: Broad, bizarre complexes occurring prematurely.
Step 7: Overall Interpretation & Clinical Correlation
Synthesise: Combine findings from steps 1-6 to name the rhythm (e.g., “Atrial fibrillation with rapid ventricular response,” “Sinus bradycardia with first-degree AV block,” “Ventricular tachycardia”).
Correlate: How does this rhythm fit with the patient’s symptoms and stability? An SVT at 160 bpm might be tolerated by a young person but cause hypotension in an elderly patient.
This rigorous process is key to accurate ECG arrhythmia interpretation UKMLA requires.
Common Tachyarrhythmias (>100 bpm)
Fast heart rates require rapid assessment, particularly differentiating narrow from broad complex.
Narrow Complex Tachycardias (Supraventricular)
QRS width <0.12s. Originates at or above the AV node.
Sinus Tachycardia
Criteria: Regular rhythm, Rate >100 bpm, Normal P waves (1:1 with QRS), Normal PR, Narrow QRS.
Cause: Physiological response (exercise, stress, pain) or pathological (fever, hypovolemia, PE, hyperthyroidism). Treat the underlying cause.
Atrial Fibrillation (AF) – Irregularly Irregular
Criteria: Irregularly irregular rhythm, No discernible P waves (chaotic baseline), Variable ventricular rate, Narrow QRS (usually).
Cause: Most common sustained arrhythmia. Risk factors include age, hypertension, heart failure, valvular disease.
Significance: Risk of stroke (requires anticoagulation assessment – CHA2DS2-VASc), potential for haemodynamic instability if rate is very fast (‘rapid AF’).
Atrial Flutter – Regular, Sawtooth Pattern
Criteria: Usually regular ventricular rhythm (can be irregular if AV block varies), No normal P waves – replaced by characteristic ‘sawtooth’ flutter waves (best seen in II, III, aVF, V1), Narrow QRS. Atrial rate typically ~300 bpm, ventricular rate depends on AV conduction (e.g., 2:1 block = 150 bpm, 4:1 block = 75 bpm).
Cause: Re-entrant circuit within the atria. Similar risk factors to AF.
Significance: Similar stroke risk to AF, requires anticoagulation. Can degenerate into AF.
Supraventricular Tachycardia (SVT) – Regular, P waves often hidden
Criteria: Regular rhythm, Rate typically 140-220 bpm, P waves often buried within the QRS or T wave (difficult to see), Narrow QRS. Often starts and stops abruptly.
Cause: Usually a re-entrant circuit involving the AV node (AVNRT) or an accessory pathway (AVRT). Common in young, healthy individuals but can occur at any age.
Management: Vagal manoeuvres, Adenosine.
Broad Complex Tachycardias
QRS width ≥0.12s. Assume Ventricular Tachycardia (VT) until proven otherwise, especially in an unstable patient or someone with known structural heart disease.
Ventricular Tachycardia (VT) – Life-threatening!
Criteria: Regular (usually) broad complex tachycardia, Rate >100 bpm (often 150-250), AV dissociation (P waves marching through QRS complexes independently) may be seen but often difficult. Specific QRS morphologies can help confirm (e.g., fusion/capture beats).
Cause: Originates from ventricular myocardium, often due to scar tissue (post-MI) or channelopathies.
Significance: Can cause haemodynamic collapse. Can degenerate into Ventricular Fibrillation (VF). Pulseless VT is a cardiac arrest rhythm.
Management: Follow Resuscitation Council UK algorithm (depends on pulse/stability).
SVT with Aberrancy (Bundle Branch Block) – The Mimic
Criteria: A supraventricular rhythm (like AF, Flutter, or regular SVT) conducted with a bundle branch block (pre-existing or rate-related), resulting in a broad QRS. Can be difficult to distinguish from VT.
Clues: History of BBB, QRS morphology identical to baseline BBB, irregularity (suggests AF with BBB). If in doubt, treat as VT.
Torsades de Pointes – Polymorphic VT
Criteria: Polymorphic VT (QRS complexes vary in shape and amplitude), appearing to ‘twist’ around the baseline. Associated with a prolonged QT interval.
Cause: Triggered by drugs that prolong the QT interval (see Master High Yield Pharmacology for UKMLA), electrolyte disturbances (low K+, low Mg++), congenital long QT syndromes.
Significance: Can degenerate into VF. Requires immediate Magnesium Sulphate administration.
Table 1: Narrow vs. Broad Complex Tachycardia: Key Differentiators
| Feature | Narrow Complex Tachycardia (SVT types) | Broad Complex Tachycardia (Likely VT) |
|---|---|---|
| QRS Width | < 0.12 s (3 small squares) | ≥ 0.12 s (3 small squares) |
| Origin | At or above AV Node | Ventricles (usually) OR SVT with Aberrancy |
| Common Examples (Regular) | Sinus Tachycardia, SVT (AVNRT/AVRT), Atrial Flutter (with regular block) | Ventricular Tachycardia (Monomorphic) |
| Common Examples (Irregular) | Atrial Fibrillation, Atrial Flutter (with variable block) | AF with BBB, Polymorphic VT (Torsades) |
| Management Priority (Unstable) | Synchronised DC Cardioversion | Synchronised DC Cardioversion (Assume VT) |
Common Bradyarrhythmias (<60 bpm)
Slow heart rates can cause symptoms like dizziness, syncope, and fatigue.
Sinus Bradycardia
Criteria: Regular rhythm, Rate <60 bpm, Normal P waves (1:1 with QRS), Normal PR, Narrow QRS.
Cause: Can be physiological (athletes), drug-induced (beta-blockers, calcium channel blockers), or pathological (sick sinus syndrome, MI). Only treat if symptomatic.
Junctional Escape Rhythm
Criteria: Regular rhythm, Rate typically 40-60 bpm, P waves absent or inverted/retrograde (occurring just before, during, or after QRS), Narrow QRS.
Cause: Occurs when the SA node fails, and the AV junction takes over as the pacemaker.
Atrioventricular (AV) Blocks
Delay or blockage of conduction between atria and ventricles. Refer to Cardiology Essentials for UKMLA for detailed management.
First-Degree AV Block
Criteria: Regular rhythm, Rate variable, P waves 1:1 with QRS, PR interval constantly prolonged (>0.20s), Narrow QRS.
Significance: Usually benign, rarely causes symptoms.
Second-Degree AV Block (Mobitz I & II)
Mobitz I (Wenckebach): Progressive lengthening of the PR interval until a P wave fails to conduct (dropped QRS). Rhythm is regularly irregular. Usually benign.
Mobitz II: PR interval is constant (can be normal or prolonged), but P waves intermittently fail to conduct (dropped QRS), often in a fixed ratio (e.g., 2:1, 3:1). Rhythm can be regular or irregular. Higher risk of progressing to complete heart block.
Third-Degree (Complete) AV Block – AV Dissociation
Criteria: Atrial rhythm (P waves) is regular, Ventricular rhythm (QRS complexes) is regular, but there is no relationship between them (AV dissociation). P waves march through QRS complexes at their own rate. Ventricular rate is slow (escape rhythm, can be narrow or broad QRS depending on escape focus).
Significance: High risk of syncope and asystole. Usually requires pacemaker insertion.
Table 2: AV Blocks Simplified
| AV Block Type | PR Interval | P : QRS Ratio | Risk |
|---|---|---|---|
| First-Degree | Constantly >0.20s | 1 : 1 | Low |
| Second-Degree Mobitz I (Wenckebach) | Progressively lengthens then drops beat | More P than QRS | Low |
| Second-Degree Mobitz II | Constant (normal or long) then drops beat | More P than QRS | High (risk of complete block) |
| Third-Degree (Complete) | No relationship (AV dissociation) | More P than QRS | Very High (risk of asystole) |
Life-Threatening Arrhythmias & Cardiac Arrest Rhythms
Rapid identification is critical in emergencies. See Emergency Medicine Essentials for UKMLA for ALS algorithms.
Ventricular Fibrillation (VF) – Shockable
Criteria: Chaotic, disorganized electrical activity. No discernible P waves, QRS complexes, or T waves. Looks like a messy squiggle.
Clinical: Cardiac arrest (pulseless, unresponsive).
Management: Immediate defibrillation + CPR.
Pulseless Ventricular Tachycardia (pVT) – Shockable
Criteria: ECG shows VT (broad complex tachycardia), but the patient has NO pulse.
Clinical: Cardiac arrest.
Management: Immediate defibrillation + CPR.
Asystole – Non-shockable
Criteria: Flat line (or near flat line). No electrical activity.
Clinical: Cardiac arrest.
Management: CPR + Adrenaline. Check leads are connected!
Pulseless Electrical Activity (PEA) – Non-shockable
Criteria: Any organized electrical activity on the ECG (can be any rhythm except VF/pVT) but the patient has NO pulse.
Clinical: Cardiac arrest.
Management: CPR + Adrenaline + Search for and treat reversible causes (Hs and Ts).
Putting It All Together: 3 UKMLA-Style Clinical Scenarios
Case 1: The Palpitating Patient with a Fast, Irregular Pulse
Vignette: A 68-year-old woman presents to A&E feeling dizzy with palpitations. Her pulse is ~140 bpm and irregularly irregular. She has a history of hypertension.
ECG Rhythm Strip: Shows an irregularly irregular rhythm, no clear P waves, narrow QRS complexes.
Interpretation: Atrial Fibrillation with rapid ventricular response (Rapid AF).
Action: Assess haemodynamic stability. If unstable, consider urgent cardioversion. If stable, rate control (e.g., beta-blocker or calcium channel blocker), anticoagulation assessment (CHA2DS2-VASc), investigate underlying cause. Follow RCUK Tachycardia Algorithm principles.
Case 2: The Elderly Patient Who Collapsed with a Slow Pulse
Vignette: An 82-year-old man presents after a collapse (syncope). On examination, his heart rate is 35 bpm, regular. Blood pressure is 90/50 mmHg.
ECG Rhythm Strip: Shows regular P waves at a rate of 70 bpm. Regular, broad QRS complexes occur independently at a rate of 35 bpm. There is no consistent relationship between P waves and QRS complexes.
Interpretation: Third-Degree (Complete) AV Block with a ventricular escape rhythm.
Action: This is a peri-arrest situation due to profound bradycardia and haemodynamic compromise. ABCDE assessment. Give Atropine (may not work if block is below AV node). Prepare for transcutaneous pacing. Urgent cardiology referral for permanent pacemaker insertion.
Sample Escalation Script (Complete Heart Block)
“Hi, Dr. Smith? This is [Your Name], FY1. I’m calling about Mr. Jones, an 82-year-old man who presented with syncope. His heart rate is 35, BP 90/50, and he looks unwell. His ECG shows complete heart block with AV dissociation and a ventricular escape rhythm. I’ve given Atropine with no response. I think he needs urgent pacing. Could you review him immediately, please?”
Case 3: The Unresponsive Patient in Cardiac Arrest
Vignette: You are called to a ward where a 75-year-old man has been found unresponsive and apneic. CPR is in progress. You attach the defibrillator pads.
ECG Rhythm Strip: Shows chaotic, disorganized electrical activity with no identifiable complexes.
Interpretation: Ventricular Fibrillation (VF).
Action: Shout “Shockable rhythm, charging!” Ensure everyone is clear. Deliver a shock. Immediately resume high-quality CPR for 2 minutes. Follow the Resuscitation Council UK ALS algorithm.
Frequently Asked Questions (FAQ) about ECG Arrhythmia Interpretation
After checking the patient’s details, the most crucial first step is to assess the rate (is it too fast or too slow?) and the rhythm (is it regular or irregular?). This initial assessment immediately narrows down the possibilities and helps you prioritise potentially life-threatening conditions like extreme bradycardia, rapid AF, or broad complex tachycardia.
While complex algorithms exist (like Brugada criteria), for UKMLA purposes, the safest approach is: assume any regular broad complex tachycardia (QRS ≥0.12s) is VT until proven otherwise, especially in older patients or those with known heart disease. Features favouring VT include AV dissociation, fusion/capture beats, extreme axis deviation, and very broad QRS (>0.14s). If the patient is unstable, treat as VT regardless.
AV dissociation means the atria and ventricles are beating independently of each other. On the ECG, you see P waves occurring at their own regular rate, and QRS complexes occurring at their own (usually slower) regular rate, with no consistent relationship between them – P waves appear randomly before, during, or after QRS complexes. It’s the hallmark of Third-Degree (Complete) AV Block and can sometimes be seen during Ventricular Tachycardia.
When the heart’s primary pacemaker (SA node) fails or conduction is blocked (e.g., high-degree AV block), a lower focus in the heart takes over to prevent asystole. This slower, backup rhythm is an escape rhythm. If it originates from the AV junction, it’s typically narrow QRS at 40-60 bpm (junctional escape). If it originates from the ventricles, it’s broad QRS at 20-40 bpm (ventricular escape). These are protective but indicate underlying pathology.
Ectopic beats are premature beats originating outside the SA node. Atrial ectopics (or Premature Atrial Contractions, PACs) originate in the atria, resulting in an early P wave (often different morphology) followed by a normal narrow QRS. They are usually benign. Ventricular ectopics (or Premature Ventricular Contractions, PVCs) originate in the ventricles, resulting in an early, broad, bizarre QRS complex with no preceding P wave. Occasional PVCs are common and often benign, but frequent, multifocal, or consecutive PVCs (‘runs’ of VT) can be more concerning, especially post-MI.
The management principles are very similar, focusing on rate control and anticoagulation based on stroke risk (using CHA2DS2-VASc, same as AF). However, rhythm control strategies can differ. Atrial flutter, being caused by a defined re-entrant circuit (usually in the right atrium), is often amenable to curative treatment with catheter ablation (specifically cavotricuspid isthmus ablation), which is less commonly curative for AF.
Pulseless Electrical Activity (PEA) is a cardiac arrest rhythm where there’s organised electrical activity but no cardiac output (no pulse). Management involves CPR and searching for/treating potentially reversible causes, commonly remembered by the “Hs and Ts”: Hypoxia, Hypovolemia, Hypo/Hyperkalemia (& other electrolytes), Hypothermia; Thrombosis (coronary or pulmonary), Tamponade (cardiac), Toxins, Tension pneumothorax.
Sick Sinus Syndrome (also known as sinus node dysfunction) is a generalised abnormality of sinus node impulse formation or propagation. ECG findings can be varied and intermittent, including persistent sinus bradycardia, sinus pauses or arrest (periods where the SA node fails to fire), sinoatrial exit block, or tachy-brady syndrome (alternating periods of slow atrial rhythms and fast supraventricular arrhythmias like AF or flutter). It often requires pacemaker insertion if symptomatic.
Yes, absolutely. Hyperkalemia is high-yield, causing peaked T waves, flattened P waves, prolonged PR, widened QRS, and eventually a ‘sine wave’ pattern leading to VF/asystole. Hypokalemia causes T wave flattening, ST depression, and prominent U waves, increasing the risk of ventricular ectopics and Torsades de Pointes. Hypomagnesemia can also prolong the QT interval and precipitate Torsades de Pointes. Hypocalcemia prolongs the QT interval, while hypercalcemia shortens it.
Several excellent online resources exist. The LITFL (Life in the Fast Lane) ECG Library is a highly recommended free resource with a vast collection of ECGs, including numerous arrhythmia examples with detailed explanations. Other reputable sites include ECG Wave Maven and academic institution websites. Consistent practice with real examples is key to building pattern recognition skills.
Conclusion
Systematic ECG arrhythmia interpretation UKMLA requires is a skill built through knowledge and structured practice. By consistently applying the 7-step framework (Rate, Rhythm, P waves, PR, QRS width, QRS morphology, Context), you can confidently approach any rhythm strip. Prioritise learning the features of common tachycardias (AF, SVT, VT) and bradycardias (Sinus Brady, AV Blocks), and crucially, the life-threatening cardiac arrest rhythms (VF, pVT, Asystole, PEA).
Remember to always correlate the ECG findings with the patient’s clinical state – treat the patient, not just the monitor. Continued practice using online libraries, question banks, and real clinical ECGs will solidify your skills for the UKMLA and ensure you are prepared for managing these common and critical conditions as a junior doctor.
Your Next Steps
Memorise the Framework: Commit the 7-step rhythm analysis approach to memory.
Learn Key Criteria: Focus on the defining criteria for high-yield arrhythmias (AF, Flutter, SVT, VT, AV Blocks). Use flashcards or tables.
Practice Systematically: Use online ECG resources like LITFL and systematically apply the 7 steps to dozens of examples.
Review ALS Algorithms: Familiarise yourself with the Resuscitation Council UK guidelines for managing tachycardias, bradycardias, and cardiac arrest rhythms.
Integrate Knowledge: Link arrhythmia recognition to relevant clinical presentations (Cardiology Essentials, Emergency Medicine Essentials) and pharmacology (High-Yield Pharmacology).
